Các cách cấu hình Loadbalance trên Mikrotik

-

Các cách cấu hình Loadbalance trên Mikrotik


* Vài lưu ý trước khi vào nội dung chính mình cần chia sẻ :
  • 1. Bài viết này mang tính chất là dành cho cá nhân để lưu trữ kiến thức cũng như kinh nghiệm bản thân đã trải qua.
  • 2. Bài viết chia sẻ phi lợi nhuân.
  • 3. Bài viết có thể làm vài bạn sẽ biểu môi rằng đơn giản thế này ai chẳng biết, post lên làm gì ==> thì nhìn lại mục "1" nhé.
  • 4. Bài viết có lấy hình ảnh và một vài nội dung trên internet, nên nếu có gì vi phạm, cảm phiền các bạn báo lại giúp mình



  • Chỉ cân bằng tải:
Code
Copy

/ip firewall mangle



add action=mark-connection chain=input disabled=no in-interface=ISP1 \



    new-connection-mark=to_ISP1 passthrough=yes



add action=mark-connection chain=input disabled=no in-interface=ISP2 \



    new-connection-mark=to_ISP2 passthrough=yes



add action=mark-connection chain=prerouting connection-mark=no-mark disabled=\



    no in-interface=ISP1 new-connection-mark=to_ISP1 passthrough=yes



add action=mark-connection chain=prerouting connection-mark=no-mark disabled=\



    no in-interface=ISP2 new-connection-mark=to_ISP2 passthrough=yes



add action=mark-connection chain=prerouting connection-mark=no-mark disabled=\



    no dst-address-type=!local in-interface=LAN new-connection-mark=\



    to_ISP1 passthrough=yes per-connection-classifier=both-addresses:2/0



add action=mark-connection chain=prerouting connection-mark=no-mark disabled=\



    no dst-address-type=!local in-interface=LAN new-connection-mark=\



    to_ISP2 passthrough=yes per-connection-classifier=both-addresses:2/1



add action=mark-routing chain=prerouting connection-mark=to_ISP1 disabled=\



    no in-interface=LAN new-routing-mark=to_ISP1 passthrough=yes



add action=mark-routing chain=prerouting connection-mark=ISP2_conn disabled=\



    no in-interface=LAN new-routing-mark=to_ISP2 passthrough=yes



add action=mark-routing chain=output connection-mark=to_ISP1 disabled=no \



    new-routing-mark=to_ISP1 passthrough=yes



add action=mark-routing chain=output connection-mark=to_ISP2 disabled=no \



    new-routing-mark=to_ISP2 passthrough=yes











/ip firewall nat



add action=masquerade chain=srcnat disabled=no out-interface=ISP1



add action=masquerade chain=srcnat disabled=no out-interface=ISP2















/ip route



add check-gateway=ping disabled=no distance=1 dst-address=0.0.0.0/0 gateway=\



    ISP1 routing-mark=to_ISP1 scope=30 target-scope=10



add check-gateway=ping disabled=no distance=1 dst-address=0.0.0.0/0 gateway=\



    ISP2 routing-mark=to_ISP2 scope=30 target-scope=10
  • Cân bằng tải + gộp băng thông Download:

Code
Copy

/ip firewall mangle



add action=mark-connection chain=prerouting disabled=no in-interface=Lan_eth \



    new-connection-mark=to_ISP1 passthrough=yes



add action=mark-connection chain=prerouting disabled=no in-interface=Lan_eth \



    new-connection-mark=to_ISP2 passthrough=yes



add action=mark-routing chain=prerouting disabled=no in-interface=Lan_eth \



    new-routing-mark=to_ISP1 passthrough=yes src-address-list=to_ISP1



add action=mark-routing chain=prerouting disabled=no in-interface=Lan_eth \



    new-routing-mark=to_ISP2 passthrough=yes src-address-list=to_ISP2



add action=mark-connection chain=prerouting connection-state=new disabled=no \



    in-interface=Lan_eth new-connection-mark=to_ISP1 nth=2,1 passthrough=yes



add action=mark-connection chain=prerouting connection-state=new disabled=no \



    in-interface=Lan_eth new-connection-mark=to_ISP2 nth=2,2 passthrough=yes



add action=add-src-to-address-list address-list=to_ISP1 address-list-timeout=\



    1d chain=prerouting connection-mark=to_ISP1 disabled=no in-interface=\



    Lan_eth



add action=add-src-to-address-list address-list=to_ISP2 address-list-timeout=\



    1d chain=prerouting connection-mark=to_ISP2 disabled=no in-interface=\



    Lan_eth



add action=mark-routing chain=prerouting connection-mark=to_ISP1 disabled=no \



    in-interface=Lan_eth new-routing-mark=to_ISP1 passthrough=yes



add action=mark-routing chain=prerouting connection-mark=to_ISP2 disabled=no \



    in-interface=Lan_eth new-routing-mark=to_ISP2 passthrough=yes











/ip firewall nat



add action=masquerade chain=srcnat disabled=no out-interface=ISP1



add action=masquerade chain=srcnat disabled=no out-interface=ISP2











/ip route



add check-gateway=ping disabled=no distance=1 dst-address=0.0.0.0/0 gateway=\



    ISP1 routing-mark=to_ISP1 scope=30 target-scope=10



add check-gateway=ping disabled=no distance=1 dst-address=0.0.0.0/0 gateway=\



    ISP2 routing-mark=to_ISP2 scope=30 target-scope=10
  • Cân bằng tải + gộp băng thông cả Download và Upload:

Code
Copy

/ip firewall mangle



add action=mark-connection chain=input disabled=no in-interface=ISP1 \



    new-connection-mark=to_ISP1 passthrough=yes



add action=mark-connection chain=input disabled=no in-interface=ISP2 \



    new-connection-mark=to_ISP2 passthrough=yes



add action=mark-routing chain=output connection-mark=to_ISP1 disabled=no \



    new-routing-mark=to_ISP1 passthrough=yes



add action=mark-routing chain=output connection-mark=to_ISP2 disabled=no \



    new-routing-mark=to_ISP2 passthrough=yes



add action=accept chain=prerouting disabled=no dst-address=192.168.0.0/24 \



    in-interface=Lan_eth



add action=mark-connection chain=prerouting disabled=no dst-address-type=\



    !local in-interface=Lan_eth new-connection-mark=to_ISP1 passthrough=yes \



    per-connection-classifier=both-addresses-and-ports:2/0



add action=mark-connection chain=prerouting disabled=no dst-address-type=\



    !local in-interface=Lan_eth new-connection-mark=to_ISP2 passthrough=yes \



    per-connection-classifier=both-addresses-and-ports:1/1



add action=mark-routing chain=prerouting connection-mark=to_ISP1 disabled=no \



    in-interface=Lan_eth new-routing-mark=to_ISP1 passthrough=yes



add action=mark-routing chain=prerouting connection-mark=to_ISP2 disabled=no \



    in-interface=Lan_eth new-routing-mark=to_ISP2 passthrough=yes











/ip firewall nat



add action=masquerade chain=srcnat disabled=no out-interface=ISP1



add action=masquerade chain=srcnat disabled=no out-interface=ISP2











/ip route



add check-gateway=ping disabled=no distance=1 dst-address=0.0.0.0/0 gateway=\



    ISP1 routing-mark=to_ISP1 scope=30 target-scope=10



add check-gateway=ping disabled=no distance=2 dst-address=0.0.0.0/0 gateway=\



    ISP2 routing-mark=to_ISP2 scope=30 target-scope=10
